4.75 inch Squeeze Packer / Drillable Bridge Plug with 10000psi working pressure

Name: 475 inch Squeeze Packer Drillable Bridge Plug with 10000psi working pressure
Brand: ZZ TOP OIL TOOLS
Price: 1 USD

Wholesale 4.75 inch Squeeze Packer / Drillable Bridge Plug with 10000psi working pressure from china suppliers

Brand Name : ZZ TOP OIL TOOLS

Model Number : SVB Squeeze Packer

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : SVB Squeeze Packer

Application : Oil Well Cementing Operation

Usage : Well Pressure Control

Size : 5 inch

Working Pressure : 10000psi

Connection : IF

Working Condition : Oil & Gas & H2S service

Working Temperature : Up to 425oF

Contact Now

SVB Squeeze Packers For Cementing Operation / Drillable Bridge Plug

SVB is the Squeeze Packer used in remedial cementing operations, also the SVB can be used as the drillable bridge plug. The squeeze packers are made of cast iron, brass, aluminum, and rubber to provide unsurpassed drillability. The Squeeze Packers can be set on electric wireline, slickline, coiled tubing, or jointed pipe with either a mechanical or hydraulic setting tool.

Features and Benefits

• The squeeze packer can control flow and pressure differential in either direction
• Allows pressure testing of workstring
• The squeeze packer can be run in quickly
• The squeeze packer can be applied in a wide range of casing grades
• Contains rugged brass mandrel, improved slips, and improved sliding valve seals
• Can be set on wireline, tubing, and drill pipe
• Can be set mechanically or hydraulically

Technical parameter of SVB Squeeze Packer

Applicable Casing size	41/2”9.5-13.5#43/4”16#5”20.3-24.2#51/2”36.4#
Max.Casing ID	106.2mm
Min Casing ID	99.3mm
Max.OD	93.0mm
Min.ID	22.1mm
Length	638mm
Max.Df ferential Pressure	10000psi
Working Temperature	-29°C~120°C
Tension Sleeve Value	30000lbs/20000lbs

4.75 inch Squeeze Packer / Drillable Bridge Plug with 10000psi working pressure
